Desktop Scanner HGS-700CU
High-Performance MICR Scanner for Processing Diverse Documents from Checks to A4 Size
This scanner is an optimized solution for the financial sector, specifically designed for processing domestic banking loan/deposit documents, checks, and vouchers. It incorporates an ultra-high resolution 600 dpi CIS, enabling precise scanning from B/W images up to 24-bit color.
It boasts superior processing speeds, handling up to 70 sheets per minute (DPM) for A4 duplex color scanning (200 dpi) and up to 100 DPM for A4 duplex B/W scanning (200 dpi). It features MICR support for accurate check data recognition and supports an inkjet endorsing function to enhance operational efficiency.
Furthermore, it offers duplex scanning for ID cards for customer identity verification to maximize the security of financial transactions.
Features
Financial-grade scanner optimized for processing loan/deposit documents, checks, and vouchers in the financial sector.
Features an ultra-high resolution 600 dpi CIS (Contact Image Sensor).
B/W, 256Gray, 24-bit color image supports
Scan Speed (Color): Up to 70 sheets per minute (dpm) A4 duplex at 200 dpi.
Scan Speed (B/W): Up to 100 sheets per minute (dpm) A4 duplex at 200 dpi.
MICR Support: Standard capability for both E13B & CMC7.
Supports Inkjet Endorsing functionality.
Duplex scanning capability for ID cards (0.7–0.8 mm thickness).
Specifications
| Scanner | |
|---|---|
| Image Sensor | Dual CIS (Contact Image Sensor) |
| Resolution | 100dpi, 200dpi, 300dpi, 400dpi, 600dpi |
| Image Depth | B/W, 256gray, 24bit color |
| Light Source | RGB |
| Scan Width | 216mm |
| Scan Speed | Max 100dpm(A4/duplex/Gray) / Max 70dpm(A4/duplex/Color) |
| Document Size | Width 54mm~216mm(ID Check, A6, A5, A4, Letter) / Length 350mm |
| Image Compression | bmp / jpg, PDF, tiff (compressed in PC) |
| MICR Reader | |
|---|---|
| E13B | 99.50% |
| CMC7 | 99.90% |
| Others | |
|---|---|
| Hopper Capability | Max 500 Sheet(70g/sqm base) |
| Stacker Capability | Max 500 Sheet(70g/sqm base) |
| No. of Stacker | 1 pocket |
| Straight Path | Yes ( for ID card and thickness document) |
| DFS | Yes (Ultra sonic) |
| Feeder type | ADF and Retard Type |
| Color drop | Red/Green/Blue drop |
| Interface & Power | |
|---|---|
| Communication | High speed USB 2.0 |
| OS | Win 7, 10, 11 (32bit & 64bit) |
| Power | Free Voltage(100V~240V, 50/60Hz) |
| S/W interface | TWAIN, Hantle API |
| Physical | |
|---|---|
| Dimension | 350mm(W) X 300mm(H) X 420mm(L) |
| Weight | 11kg (approx) |
| Option | |
|---|---|
| Endorsement | Inkjet 1 Line(HP) |
| Counterfeit Detection | Korean Domestic Market only |
